LASER C SERIES Maintenance manual Page 261

Maintenance manual
B–70115EN/03
9. SETTING AND ADJUSTMENT
259
The operator has two modes; MONITOR mode and FUNCTION mode.
In the MONITOR mode, the monitor screen to display operation status
appears. In the function mode, the function screen appears. The function
screen has a hierarchical structure used to change operation status.
" 1 Command "
2 Initial "
3 Function "
4 Option "
Function 4 OR FR

}
Fixed field
Operation status/screen hierarchy
Used to display the operation status in the monitor mode and the screen
hierarchy in the function mode.
Operation
mode
Status Display
Monitor
screen
Operation
status
ST TR FR RR AJ RT UV
At tripping
time
At stop
time
At forward
run
At reverse
run
f
Alignment
0
Start
Under
voltage
Stop
DB
During standby after immediate return
Function
screen
Screen
hierarchy
1st layer 2nd layer 3rd layer 4th layer
Display title
Displays the current mode name or hierarchical layer name.
Total items
Displays the current mode name or the total number of items in the
selected hierarchical layer.
Operation command
Displays the current operation command status.
Operation mode Display
Monitor/function mode
Remote operator
OR
Terminal
OT
Optional PCB 1
O1
Optional PCB 2
O2
D MONITOR/FUNCTION
mode
D Fixed field (Top row on
screen)
Previous page
Next page
