F. REFIXING AND REPLACING
GAS TUBE
462
F
REFIXING AND REPLACING GAS TUBE
Replacing both of polyethylene and copper tubes is the same. Take care
only for the combination between tube materials and ferrule materials.
Polyethylene tube : nylon ferrule (back, front)
(A98L–0004–0348/2–N : 1/4″)
(A98L–0004–0348/3–N : 3/8″)
(A98L–0004–0348/4–N : 1/2″)
Copper tube : brass ferrule (back, front)
(A98L–0004–0348/2–B : 1/4″)
(A98L–0004–0348/3–B : 3/8″)
(A98L–0004–0348/4–B : 1/2″)
Take care also not to introduce dust into laser because exposure to ambient
air is inevitable.
