LASER C SERIES Maintenance manual Page 397

Maintenance manual
B–70115EN/03
D. PARAMETERSAPPENDIX
397
#7
TEM15009
#6
BCG
#5
BEM
#4
AFZ
#3
BS2
#2
BS1
#1
AS2
#0
AS1
This parameter is used for the laser gas mixing function to record and
monitor the operating state of the mixer. This parameter is automatically
set, so this parameter need not be set manually.
AS2,AS1 The state of tank A is indicated.
AS2 AS1 :
0 0 Tank A is being filled with gas.
0 1 Gas is being mixed in tank A.
1 0 Gas is being supplied from tank A.
1 1 A preparation is being made to fill tank A with gas.
BS2,BS1 The state of tank B is indicated.
BS2 BS1 :
0 0 Tank B is being filled with gas.
0 1 Gas is being mixed in tank B.
1 0 Gas is being supplied from tank B.
1 1 A preparation is being made to fill tank B with gas.
AFZ 1 : Does not include the Z–axis in calculation for actual feedrate display.
0 : Includes the Z–axis in calculation for actual feedrate display.
BEM 1 : Gas cylinder supply pressure is normal.
0 : Gas cylinder supply pressure has dropped.
BCG 1 : The gas cylinder is not replaced.
0 : The gas cylinder is replaced.
TEM 1 : The tank supply pressure is normal.
0 : The tank supply pressure has dropped.
#7
15011
#6 #5 #4 #3 #2 #1 #0
EDS
EDS 0 : During return distance execution in edge machining or start–up
machining, the conventional cutting condition is used.
1 : During return distance execution in edge machining or start–up
machining, the laser power, assist gas type, and assist gas pressure of
the piercing condition for edge machining are used.
