LASER C SERIES Maintenance manual Page 401

Maintenance manual
B–70115EN/03
D. PARAMETERSAPPENDIX
401
[Setting range] 0 to 255
[Unit] 0.01 MPa
15056 EPCAGS
EPCAGS Type of piercing assist gas
Set a type of assist gas to be used for piercing.
[Setting range] 0 to 7
15057 ERTLGH
ERTLGH Return distance
Set a return distance from the top of a corner to the next block.
[Setting range] 0 to 65000
[Unit] 0.001 mm
15058 ERTF
ERTF Return feedrate
Set a return feedrate to be used for movement from the top of a corner to
the next block.
[Setting range] 0 to 9999
[Unit] 1 mm/min
15059 ERTPWR
ERTPWR Peak return power value
Set a peak return power value to be used for movement from the top of a
corner to the next block.
[Setting range] 0 to 7000
[Unit] WAT T
15060 ERTFRQ
ERTFRQ Return frequency
Set a return frequency to be used for movement from the top of a corner to
the next block.
[Setting range] 5 to 2000
[Unit] Hz
15061 ERTDTY
ERTDTY Return duty ratio
Set a return duty ratio to be applied to movement from the top of a corner
to the next block.
[Setting range] 0 to 100
[Unit] %
