LASER C SERIES Maintenance manual Page 298

Maintenance manual
B–70115EN/03
10. REPLACEMENT PROCEDURES
296
7) Tighten the nut of the damping rubber. Carefully follow the
procedure below to prevent the damping rubber from being twisted
and damaged.
Tightening procedure (C1500B, C2000B, C2000C, C3000C,
C6000B)
1. Position the antivibration rubber such that its parting line is
clearly visible (to enable any twisting to be observed).
2. Temporarily tighten the bolt.
3. Tighten the nut to a torque of 12 N@m.
4. Loosen the bolt, and eliminate the twist caused in step 3.
5. Hold the lower part of the rubber using water pliers, to
prevent the rubber from twisting, then tighten the bolt to a
torque of 12 N@m.
6. Check whether the rubber is twisted, by observing the
parting line (the displacement between the top and bottom
of the line must not exceed 2 mm).
8) Connect the cooling water tubes and the power and ground cables.
9) Supply a prescribed amount of turbo oil to the turbo–blower.
10) Check that there are no cooling water leaks, turn on the oscillator,
then check for gas leakage.
11) Set an oil level alarm for the turbo–blower as described in Section
9.2, “Setting the Turbo PCB.”
