LASER C SERIES Maintenance manual Page 405

Maintenance manual
B–70115EN/03
D. PARAMETERSAPPENDIX
405
#7
15088
#6 #5 #4 #3 #2 #1 #0
IPC
IPC For power control mode specification (models A and B):
0 : The format for specifying S and F in the same block is used.
1 : The format for specifying G63 or entering the external signal
(G224#1) is used.
#7
LP815089
#6
LP7
#5
LP6
#4
LP5
#3
LP4
#2
LPZ
#1
LPY
#0
LPX
LP* 0 : Does not use the *–axis for speed calculation with the power control
function.
1 : Uses the *–axis for speed calculation with the power control function.
When no axis is specified, the specification of the first axis (LPX) and the
second axis (LPY) is assumed for operation.
Usually, specify those axes that are used for interpolation. Do not specify
axes such as a PMC axis and synchronous axis for simple synchronous
control.
15090 Minimum output power
[Unit] W
[Setting range] 0 to 7000
15091 Minimum pulse frequency
[Unit] Hz
[Setting range] 5 to 2000
15092 LDTYLW
LDTYLW0245
LDTYLW Duty lower limit (Setting data)
When PRM No. 15000 [200]/bit 0 is valid, power control is performed by
this value.
If the duty cycle is reduced according to the feedrate, the specification of a
value less than this value will cause this value to be clamped.
[Setting range] 0 to 100
[Unit] %
[How to set] This parameter can be set using the laser setting screen.
D.7
PARAMETERS FOR
POWER CONTROL
