LASER C SERIES Maintenance manual Page 415

Maintenance manual
B–70115EN/03
D. PARAMETERSAPPENDIX
415
[Unit] WATT
[Standard setting] Refer to the parameter data sheet delivered with the machine.
15212 PPCLMT
PPCLMT Maximum specifiable power when the duty ratio is not clamped
If PRM No. 15213 does not clamp the duty ratio to 50%, and a specified
power after power compensation and power feedback processing exceeds
the setting in this parameter, the power is clamped to the setting.
If the duty ratio is clamped by PRM No. 15213, the power is clamped to
the value specified with PRM No. 15207.
[Setting range] 0 to 32767
[Unit] WATT
15213 PPWMAX
PPWMAX Duty ratio clamp criterion
When a specified power multiplied by an override value exceeds the value
set in this parameter, the duty ratio is clamped to 50% (fixed value), and
the peak value is clamped to the value set in PRM No. 15210.
[Setting range] 0 to 32767
[Unit] WATT
15215 PWCM
PWCM0259
PWCM Power input calibration coefficient
The laser power is monitored through the rear mirror. This parameter
specifies the calibration coefficient used to convert the monitored value to
the actual laser power, as output from the output mirror.
[Setting range] 102 (0.1 2
10
) to 10240 (10 2
10
)
[Units] 1/1024
[Standard setting] Refer to the parameter data sheet delivered with the machine.
NOTE
If 0 is specified, 1024 (1 2
10
) is assumed.
15216 TCNST
TCNST0262
TCNST Power display filter time constant
This is the filter time constant with which fluctuation in power display is
suppressed.
[Setting range] 0 to 32767
[Unit] msec
[Standard setting] Refer to the parameter data sheet delivered with the machine.
