LASER C SERIES Maintenance manual Page 441

Maintenance manual
B–70115EN/03
D. PARAMETERSAPPENDIX
441
#7
815700
#6
7
#5
6
#4
5
#3
4
#2
Z
#1
Y
#0
X
X – 8 Set axes required to calculate a move command for a mirror movement
axis.
1 : Used for move command calculation
0 : Not used for move command calculation
NOTE
Set the bits for nonexistent axes to 0.
#7
815701
#6
7
#5
6
#4
5
#3
4
#2
Z
#1
Y
#0
X
X – 8 Selects a polarity for move command calculation for each axis when
calculating a move command for a mirror movement axis.
1 : Selects the positive polarity for calculation.
0 : Selects the negative polarity for calculation.
NOTE
Set the bits for nonexistent axes to 0.
#7
15702
#6 #5 #4 #3 #2 #1
FMSW
#0
TRAXC
TRAXC 1 : Includes tracing axis travel distance data in U–axis move command
calculation in tracing control.
0 : Does not include tracing axis travel distance data in U–axis move
command calculation in tracing control.
FMSW 1 : Enables constant optical path length control.
0 : Disables constant optical path length control.
15703 MIRAXS
MIRAXS Axis selection for mirror movement
Specify mirror movement axes in this parameter. The X–axis, Y–axis,
and Z–axis cannot be specified. If there is a simple synchronized axis, the
fifth and later axes can be specified.
[Setting range] 4 to 8
D.24
PARAMETERS FOR
CONSTANT OPTICAL
PATH LENGTH
CONTROL
