LASER C SERIES Maintenance manual Page 427

Maintenance manual
B–70115EN/03
D. PARAMETERSAPPENDIX
427
15320 LPCD
LPCD2C Command power for power calibration coefficient calculation (valid
when EGE = 1)
If the automatic aging function is enabled, a power calibration coefficient
is calculated after aging ends.
[Setting range] 0 to 7000
[Unit] W
[Standard setting] Refer to the parameter data sheet delivered with the machine.
15321 LFCD2C
LFCD2C Oscillation frequency command for power calibration coefficient
calculation (valid when EGE = 1)
[Setting range] 5 to 2000
[Unit] Hz
[Standard setting] 100
15322 LDCD2C
LDCD2C Pulse duty cycle command for power calibration coefficient calculation
(valid when EGE = 1)
[Setting range] 0 to 100
[Unit] %
[Standard setting] 100
15323 PCLTMC
PCLTMC Command time for power calibration coefficient calculation (valid when
EGE = 1)
[Setting range] 0 to 32767
[Unit] sec
[Standard setting] Refer to the parameter data sheet delivered with the machine.
D.16
AUTOMATIC AGING
FUNCTION
