LASER C SERIES Maintenance manual Page 130

Maintenance manual
B–70115EN/03
5. MAINTENANCE
128
The maintenance parts are listed below. Refer to the following tables for
maintenance unit and part specification information.
NONREPAIRABLE PARTS
MODEL QUANTITY
NAME SPECIFICATION
C1500B C2000B C2000C C3000C C3000D C4000A C6000B
NOTE
OUTPUT COUPLER
A98L–0001–0981 1 0 0 0 0 0 0
POISON
A98L–0001–0981/B 1 0 0 0 0 0 0
A98L–0001–0960 0 1 1 0 0 0 0
A98L–0003–0015/B 0 0 0 0 1 0 0
#1
A98L–0003–0015/D 0 0 0 1 (1) 0 0
A98L–0003–0027 0 0 0 0 0 0 1
A98L–0003–0036 0 0 0 0 0 1 0
REAR MIRROR
A98L–0001–0750 1 0 0 0 0 0 0
A98L–0001–0961 0 1 1 0 0 0 0
A98L–0001–0757/B 0 0 0 0 0 0 1
A98L–0003–0016/B 0 0 0 0 1 0 0
#1
A98L–0003–0016/C 0 0 0 1 (1) 0 0
A98L–0003–0037 0 0 0 0 0 1 0
FOLDING MIRROR
A98L–0001–0615 0 0 0 0 0 0 0
A98L–0001–0615/B 3 3 3 4 4 6 0
A98L–0001–0866/B 0 0 0 0 0 0 4
FOLDING MIRROR
anti–reflection #1
A98L–0003–0019
(1) (1) (1) (1) (1) (1) 0 OPTION
Non–polarizing mirror
(0 degree shift) #2
A98L–0001–0616/C
(2) (2) (2) (1) (1) (1) 0 OPTION
ramda/4 retardar mirror
(circular polarizer) #2
A98L–0001–0617/C
0 0 0 (1) (1) (1) 0 OPTION
O–RING FOR OC, RM
A98L–0001–0619/1025 2 0 0 0 0 0 0
JB–OR4D–P28 2 0 0 0 0 0 0
A98L–0001–0619/2030 0 2 2 2 2 2 0
A98L–0001–0619/2031 0 0 0 0 0 0 2
JB–OR4D–P38 0 2 2 2 2 2 2
O–RING FOR
JB–OR4D–G55 3 3 3 4 4 6 0
FOLDING MIRROR
JB–OR4D–G65 0 0 0 0 0 0 4
5.4
MAINTENANCE
PARTS
#1
