Replace the FS16–L interface PCBs on the oscillator side as follows:
When IF PCB (A02B–0128–C202)
(1)Replacing the upper PCB (A16B–1110–0260)
1) Turn off the power to the CNC, then turn off the power to the laser
oscillator. In addition, open the main circuit breaker for the laser
oscillator.
2) Disconnect the cables from connectors CN11 to CN18, CN23 to
CN25, JD1B (or COP1B), CN34, MA1, MB1, MP1, and CP87, as
well as those connected to the terminal block.
3) Remove the PCB from the ten PCB holders, by tilting the holder
claws outwards.
4) Mount a new PCB by reversing steps 2) and 3). Connect the cables,
noting the alignment marks. Ensure that no terminals are loose.
(2)Replacing the lower PCB (A16B–2100–0080)
1) Turn off the power to the CNC, then turn off the power to the laser
oscillator. In addition, open the main circuit breaker for the laser
oscillator.
2) Disconnect the cables from the interface PCB, with the exception
of those connected to MA1, MB1, MP1, and CP87.
3) Remove the screws then remove the entire PCB unit (two PCBs:
A16B–1110–0260 and A16B–2100–0080).
4) Remove the upper PCB (A16B–1110–0260) from the ten PCB
holders, by tilting the holder claws outwards. (Also disconnect the
cables from MA1, MB1, MP1, and CP87.)
5) Mount the upper PCB (A16B–1110–0260), removed in the
previous step, on a new lower PCB (A16B–2100–0080). Then,
connect the cables to MA1, MB1, MP1, and CP87.
6) Mount the PCB unit by reversing steps 2) and 3). Connect the
cables, noting their alignment marks. Ensure that no terminals are
loose.
When IF PCB (A16B–2100–0141)
For replacement, use the same procedure as described in Section 10.1.3.
10.1.4
Replacing the FS16–L,
FS16i–L Interface
PCBs on the Oscillator
Side
