LASER C SERIES Maintenance manual Page 136

Maintenance manual
B–70115EN/03
5. MAINTENANCE
134
NAME NOTE
MODEL QUANTITY
SPECIFICATIONNAME NOTE
C6000BC4000AC3000DC3000CC2000CC2000BC1500B
SPECIFICATION
FET MODULE PCB A20B–1006–0050 8
STEPUP
TRANSFORMER PCB
A20B–1006–0070 1
RF INVERTER PCB A20B–1006–0060 1
DIODE
A50L–2001–0257/F 6
A50L–2001–0257/R 6
DIODE HEAT SINK A A50L–6001–0569 4
DIODE HEAT SINK B A50L–6001–0570 4
This column is quantity of PSU parts per one LPSU.
(B204, B205)
DIODE SUPPORT A A250–0803–X008 4
DIODE SUPPORT B A250–0803–X009 4
DIODE PLATE A A250–0803–X006 1
DIODE PLATE F A250–0803–X011 1
DIODE PLATE G A250–0803–X012 1
ISOLATION SHEET A50L–8001–0193 2
FET MODULE PCB
A20B–1007–0140 1
A20B–1007–0150 1
STEPUP
TRANSFORMER PCB
A20B–1006–0071 1
This column is quantity of PSU parts per one LPSU.
(B206, B207)
DIODE
A50L–2001–0257/F 6
A50L–2001–0257/R 6
FET MODULE PCB
A20B–1007–0140 1
A20B–1007–0150 1
STEPUP
TRANSFORMER PCB
A20B–1006–0131 1
This column is quantity of PSU parts per one LPSU.
(B208)
DIODE
A50L–2001–0257/F 6
A50L–2001–0257/R 6
FET MODULE PCB
A20B–1007–0140 1
A20B–1007–0150 1
STEPUP
TRANSFORMER PCB
A20B–1007–0132 1
This column is quantity of PSU parts per one LPSU.
(B209)
DIODE A50L–2001–0439 6
