LASER C SERIES Maintenance manual Page 180

Maintenance manual
B–70115EN/03
6. TROUBLESHOOTING
178
#7
POV7G223
[G147]
#6
POV6
#5
POV5
#4
POV4
#3
POV3
#2
POV2
#1
POV1
#0
POV0
POV7 – POV6 Power override signal (input)
[CNC→PMC status display]
#7
F220
[F171]
#6
MWRM
#5 #4
SHTONL
#3
SHTOFL
#2 #1 #0
MWRM Laser power alarm signal (output)
SHTONL Shutter on state signal (output)
SHTOFL Shutter off state signal (output)
#7
BEAMF221
[F172]
#6
LSTR
#5
RFHV
#4
CLON
#3
WAIT
#2
PURGE
#1
LRDY
#0
LARM
BEAM Beam on signal (input)
LSTR In–oscillating signal (output)
RFHV Base in–discharging signal (output)
CLON Chiller start request signal (output)
WAIT Gas pressure in–controlling signal (output)
PURGE Purge completed signal (output)
LRDY Discharge start prepared signal (output)
LARM Laser alarm signal (output)
#7
F222
[F173]
#6
CW
#5
PULSE
#4 #3 #2
AG3
#1
AG2
#0
AG1
CW Continuous wave mode state output signal (output)
PULSE Pulse mode state output signal (output)
AG1 – AG3 Assist gas select signal (output)
