LASER C SERIES Maintenance manual Page 430

Maintenance manual
APPENDIX
B–70115EN/03
D. PARAMETERS
430
15332 LFCMD2
LFCMD2 Oscillation frequency command value for power calibration
[Setting range] 5 to 2000
[Unit] Hz
[Standard setting] 100
15333 LDCMD2
LDCMD2 Pulse duty cycle command during power calibration and aging
[Setting range] 0 to 100
[Unit] %
[Standard setting] 100
15334 NES
NES Number of aging operations (valid when EGE = 1)
This parameter specifies the number of times the aging sequence is
executed. The number of aging operations (0 or 2 to 7) is automatically
set, depending on the halt time, when the automatic aging function is
enabled.
[Setting range] 0, 2 to 7 (Automatically set by the CNC)
15335 LOFTIMY
LOFTIMY Aging time data 1 (valid when EGE = 1)
When the automatic aging function is enabled, the year when the
oscillator was stopped previously is recorded.
[Setting range] 1 to 65535 (Automatically set by the CNC)
15336 LOFTIMM
LOFTIMM Aging time data 2 (valid when EGE = 1)
When the automatic aging function is enabled, the month when the
oscillator was stopped previously is recorded.
[Setting range] 1 to 12 (Automatically set by the CNC)
15337 LOFTIMD
LOFTIMD Aging time data 3 (valid when EGE = 1)
When the automatic aging function is enabled, the day when the oscillator
was stopped previously is recorded.
[Setting range] 1 to 31 (Automatically set by the CNC)
