B–62884EN/01

3. OPERATION

105

2) Close the dialog box by clicking the [Cancel] button or pressing

the

Esc

key.

Caution

In the case of a CNC system in which programs are backed

up to PMC flash memory, place the CNC in the emergency

stop state before starting backup.

This function establishes or disconnects a communication link between

open CNC and PMC. The on–line function can be used only while a

communication link is established.

The communication link is established automatically as soon as the

computer is executed.

(1) Menu position

To display the “Communication” dialog box, display the [4.

Communication] pull–down menu, then select [Communication]

from the menu.

Communication

4. Communication

(2) Displaying the dialog box

(a) Displaying the “Communication” dialog box

Selecting [Communication] causes the following dialog box to

appear:

Communication

status

Cancel

Start

communica-

tion dialog

box

Start or stop

communica-

tion

Fig.3.4.5 (a)

3.4.5

Communication
