Open CNC (Ladder Editing Package) Operators manual Page 206

Operators manual

Page of 328

/ 328

B–62884EN/01

3. OPERATION

201

D It is impossible to use space, kana, kanji, and special

characters (such as *, #, and @).

D Some character strings are unusable.

If one such character string is entered as a password, an error

message is displayed. In such a case, use another character

string.

D An entered password is not displayed on the screen.

D If the

Enter

key is pressed before any valid password is

specified, use of a password is not specified.

→ If password=RW&R go to 6).

If password=R go to 10).

D When

Esc

is pressed, an attempt to specify a password is

discontinued.

→ Go to 1).

4) The password configuration screen appears.

Verification (R)

5) You will be prompted to enter the same password as entered

before, to ensure that your password was entered correctly.

D When the password entered this time matches one that was

entered before, it is accepted.

D When they do not match, the message ”Password mismatch”

is displayed.

You are allowed to retry entering twice.

D When

Esc

is pressed, an attempt to specify a password is

discontinued.

→ Go to 1).

If password=R is specified.

→ Go to 10).

6) The password (R/W) set screen appears.

Enter password (R/W)

7) Enter a password (R/W).

D A password that can be used is a combination of 8 or less

letters and/or numerals.

D Uppercase and lowercase letters are not distinguished from

each other. (If a lowercase letter is entered, it is assumed to

be uppercase.)

D It is impossible to use space, kana, kanji, and special

characters (such as *, #, and @).

D Some character strings are unusable.

If one such character string is entered as a password, an error

message is displayed. In such a case, use another character

string.

D An entered password is not displayed on the screen.

D If the

Enter

key is pressed before any valid password is

specified, use of a password is not specified.

→ Go to 10).
