Open CNC (Ladder Editing Package) Operators manual Page 190

Operators manual
B–62884EN/01
3. OPERATION
185
Each parameter file of this software can be rewritten using a commercially
available text editor so that the output format shown in each of the
following frames can be changed.
Diagram output
AMROFTRP. DAT
1. Change the paper selection
name
2. Set the top margin
3. Set the net spacing
4. Set the printer model and
paper
CROSSINF. DAT
(Setting the cross-reference
list output format)
8. Set the output format guid-
ance information
9. Set the output information
10.Specify the output format
11.Set the read/write coil guid-
ance information
12.Specify the linefeed
13.Specify the page break
5. Set the line spacing
6. Set the left margin
(Message file)
7. Set the title of printout
PR201-10 . INF
PR201-15 . INF
PR201-A4 . INF
PR10-A . INF
PR15-A . INF
PRA4-A . INF
ESC-P-10 . INF
ESC-P-15 . INF
ESCP10-A . INF
ESCP15-A . INF
FANUC-10 . INF
For these parameter files, do not change any item not described here.
(1) Changing the paper selection name
This item makes it possible to change the name of each choice during
diagram output format selection.
Name of file to be
edited
Point of change Settings
AMROFTRP.DAT #10-A=10-inch/ASCII
#10-G=10-inch/graphic
#15-A=15-inch/ASCII
#15-G=15-inch/graphic
#A4L-A=A4 portrait/ASCII
#A4L-G=A4 portrait/graphic
Arbitrary character string
consisting of up to 30
half-size (or 15 full-size)
characters
Note
#A4L-A=and #A4L-G=are unavailable in the output to
VP1000.
3.5.3.5
Print Format-2
(AMOFTRP, DAT/*
.INF/Message File)
Previous page
Next page
