Open CNC (Ladder Editing Package) Operators manual Page 316

Operators manual

Page of 328

/ 328

F. TOOL FOR CHANGING MESSAGE DATA

(CHGMES)

B–62884EN/01

312

Basic message ladder

Source format

program

COMPILATION

Object file

INPUT/OUTPUT (F4: Handy File)

Handy file format

file

FLOPPY MEMORY CARD

(Note)

CNC

Message for changing+Dummy ladder

Source format

program

Handy file format

file

FLOPPY MEMORY CARD

Only message data for changing of ROM file

Loading at [I/O]screen operation of PMC.

Handy file

format file

Changing to message ROM data(Using this function)

↓↓

CHGMES [In. file] [Out. file] [pmc type] ([Comp. file])

*1 *2 *3

Object file

Generation, Editing

Check the SYMBOL top

address by memory map

display.

(Note)

Note

It is possible to load by memory card only for FS16–B, FS18–B, FS–20, FS21–B, and FS15–B

(PMC–NB).

Please refer to the following manual about detailed operation of loading by the memory card

or handy file. It is not possible to load on boot screen.

FANUC PMC MODEL PA1/PA3/RA1/RA2/RA3/RB/RB2/RB4/RC/RC3/RC4/NB

PROGRAMMING MANUAL (LADDER LANGUAGE) (B–61863E/06)
