Open CNC (Ladder Editing Package) Operators manual Page 227

Operators manual
3. OPERATION
B–62884EN/01
222
Program option set–up
[C: ¥DATA¥SAMPLE ]
[Compile]
condense :[OFF/ON]
symbol/comment : [NOT USE/USE]
net comment : [NO/POINTERS]
password : [NO/RW&R/RW/R]
1 EDIT 2 PRINT 3 COMPIL 4 DECOMP5 I/O 6 SET–UP 7 MNEEDT8 UTILTY 9 ONLINE 10 END
Fig.3.5.7.1
The user can set the decompile function options as described below.
These options, when set, are used as the initial values of the off–line
function decompile options, or are used for the decompile processing
performed with the on–line functions.
For details of each option, see Section 3.5.5.
(1) Symbol merge
This option specifies whether to merge source program data and
object file symbol/comment data at decompile time.
[NO] : Does not merge symbol and comment data.
[SOURCE] : Gives priority to the source data when
duplicate addresses exist in the source
program and the symbol data of the object
file.
[MEMORY CARD] : Gives priority to the object file data when
duplicate addresses exist in the source
program and the symbol data of the object
file.
3.5.7.2
Decompile
