4. ERROR MESSAGE LIST
241
Number Message Contents
C:E–3021 FILE READ ERROR. HIT ANY KEY The source program I/O module file (IOMODULE) cannot be read.
C:E–3022 FILE WRITE ERROR. HIT ANY KEY Data cannot be written to the source program I/O module file (IOMO-
DULE) or control file (CONTROL).
C:E–3023 INPUT DATA INVALID Input data is invalid. Press F3 [HELP] to confirm the input procedure.
C:E–3024 APPOINTED GROUP NOT EXIST The specified group does not exist. Press F3 [HELP] to confirm the
input value range.
C:E–3025 APPOINTED BASE NOT EXIST The specified base does not exist. Press F3 [HELP] to confirm the
input value range.
C:E–3026 APPOINTED SLOT NOT EXIST The specified slot does not exist. Press F3 [HELP] to confirm the input
value range.
C:E–3027 APPOINTED ID CODE NOT EXIST The specified module does not exist. Press F3 [HELP] to confirm the
module names that can be specified.
C:E–3028 INPUT KEY NOT USED
C:E–3030 ADDRESS APPOINT ILLEGAL The specified module cannot be used at this address. Check whether
the output module is specified at address X and whether the input
module is specified at address Y.
C:E–3032 THE SAME GROUP,BASE AND
SLOT ARE ALREADY SPECIFIED.
The specified group, base, and slot have already been assigned
modules.
Specify different group, base, and slot numbers.
C:E–3033 INVALID CHANNEL NO. APPOINT The specified channel does not exist. Press F3 [HELP] to confirm
which channels can be specified.
C:E–3034 INVALID DATA, EXCEPT ’0’, IS SPE-
CIFIED AT THE SLOT OF XXX AS
I/O UNIT B.
For I/O Unit–B (xxx:power–on/off information), a slot other than slot
0 cannot be specified. Specify slot 0.
Number Message Contents
C:W–4020 THE SAME GROUP,BASE AND
SLOT ARE ALREADY SPECIFIED.
The specified group, base, and slot have already been assigned
modules. Check whether the same numbers can be assigned for the
group, base, and slot.
C:W–4021 INVALID DATA, EXCEPT ’0’, IS SPE-
CIFIED AT THE BASE OF I/O UNIT
B.
For the I/O Unit–B module, a base other than base 0 cannot be speci-
fied. Specify base 0.
C:W–4022 BOTH I/O UNIT–A AND UNIT–B
ARE SPECIFIED IN THE SAME
GROUP.
I/O Unit–A and I/O Unit–B cannot be assigned to the same group.
Specify different groups.
4.3
C : I/O MODULE
EDITING
4.3.1
Error
4.3.2
Warning
