Open CNC (Ladder Editing Package) Operators manual Page 209

Operators manual
3. OPERATION
B–62884EN/01
204
Source program name : C:¥DATA¥SAMPLE
Decompile normal end
Decompile completed error count=000000 warning count=000000
Decompile PMC–RB4 <0>[C:¥FLADDER¥ ]
1 EXEC 2 MAP 3 ERROR 4 MERGE 5 SYMBOL 6 7 8 9 10 END
Fig.3.5.5.1 (b) Decompile end Screen
(4) Termination
[Operation]
1) Select [END].
2) The screen display returns to the main menu screen.
(1) Merge
In case the existent file is specified for output source program when
decompiling, the existent source program is deleted and new source
program is created with the contents of object file.
In this case it is possible to merge the Ladder in object file with the
Symbol/Commnet in source program by specifying the
undermentioned function–key.
Source program name : C:¥DATA¥SAMPLE
V Output to source program
SYMBOL & COMMENT
Merge [F4] YES
Duplicated symbol definition [F5] MEMORY CARD DATA (effective)
Decompile PMC–RB4 <0>[C:¥FLADDER¥ ]
1 EXEC 2 3 4 MERGE 5 SYMBOL 6 7 8 9 10 END
Fig.3.5.5.2 Decompile Menu Screen
3.5.5.2
Decompile Option
Previous page
Next page
