Open CNC (Ladder Editing Package) Operators manual Page 235

Operators manual
3. OPERATION
B–62884EN/01
230
Note
When specifying YES in Item 3 above (whether an
operator’s panel is used), specify the KEY address, LED
address, KEY image address, and LED image address as
follows:
3 YES X0000 Y0000 R0000 R0010↓
(b) Title (common to all models)
%@1↓
01 MACHINE TOOL BUILDER NAME↓
02 MACHINE TOOL NAME↓
03 CNC & PMC NAME↓
04 PMC PROGRAM NO.↓
05 EDITION NO.↓
06 PROGRAM DRAWING NO.↓
07 DATE OF PROGRAMING↓
08 PROGRAM DESIGNED BY↓
09 ROM WRITTEN BY↓
10 REMARKS↓
%↓
[EOB]
(c) Symbols and comments (common to all models)
%@2–C
R0200.0 UNIT–3–POWER
$1 ’KEEP POWER ON’ ’KEEP UNIT–3 POWER ON’
R0200.1 UNIT–2–ACT
$1 ’$’OIWER$$’ ’KEEP UNIT–4 $$POWER$’ ON’
R0300.0
$1 ’KEEP POWER ON’ ’KEEP UNIT–4 POWER ON’
P0008 OPEN–FRONT
$1 ’OPEN FRONT COVER’
L0100 INITIALIZE
$1 ’’ ’INITIALIZE OF SEQUENCE’
%
[EOB]
Display of
symbol/comment
Symbol
Coil Comment
Relay comment
Control code
no Relay comment
