4. ERROR MESSAGE LIST

B–62884EN/01

244

Number ContentsMessage

E:E–3123 ILLEGAL SUBPROGRAM NAME An invalid subprogram name was input.

E:E–3124 TOO DEEP NESTING OF SUB–

PROGRAM

E:E–3125 SAME SUB–PROGRAM NAME

EXISTS

E:E–3126 THE ZOOM NESTING CONDITION

WILL BE CANCELLED, IF YOU

SELECT TO ZOOM ’∗∗∗∗∗∗∗∗’.

E:E–3127 SOURCE PROGRAM OF

ANOTHER FORMAT EXISTS

A Format–B and C programs, having the same name as that specified

for the Copy/Move to file function, was found to exist during Format–A

program editing.

E:E–3128 ILLEGAL SYMBOL A value that cannot be used as a symbol was input during symbol

editing.

E:E–3129 PROGRAM OPEN ERROR

E:E–3130 PROGRAM NOT EXIST

E:E–3131 NOT EXIST APPOINT DATA SIZE

E:E–3132 PROGRAM NOT READ

E:E–3133 PROGRAM NOT WRITE

E:E–3134 DIRECTORY NOT EXIST

E:E–3135 LADDER DATA NOT EXIST

E:E–3136 PROGRAM IS OPENED

E:E–3137 PROGRAM NAMES LIMIT OVER

E:E–3138 CAN NOT RENAME LATMP An attempt was made to perform renaming after editing LATMP with

the File function.

E:E–3139 PROGRAM NOT EXIST

Number Message Contents

E:E–3200 ILLEGAL SOURCE CODE. A read error occurred when reading the specified intermediate code

file.

E:E–3201 BUFFER SIZE OVER. An intermediate code exceeds the Edit buffer size.

E:E–3202 NUMBER OF NEST BRANCH TOO

BIG.

The maximum allowable number of branch nests has been

exceeded.

E:E–3203 NUMBER OF BRANCH TOO BIG. The maximum allowable number of branches has been exceeded.

E:E–3204 SIZE OF TABLE BUFFER TOO BIG. The maximum allowable number of element tables has been

exceeded.

E:E–3205 UNCONNECTED STEP

SEQUENCE DIAGRAM.

The step, transition, branch, or line is not continuous.

E:E–3206 SELECTED BRANCH ERROR. The start side of the select branch does not agree with its end side.

E:E–3207 PARALLEL BRANCH ERROR. The start side of the parallel branch does not agree with its end side.

E:E–3208 SYNTAX ERROR. The sequence in the select branch is other than ”transition to step to

transition.” Or, the sequence in the parallel branch is other than ”step

to transition to step.”

4.5.3

Error (at Editing Step

Sequence)
