3. OPERATION

B–62884EN/01

188

(7) Setting the title of printout

This item can change the title of a diagram.

Name of file to be edited Point of change Settings

PRTOUT. JPN.

PRTOUT. ENG.

@ SYS

TITLE

(*** SYSTEM & PARAMETER ***) ;

@ CMT

TITLE

(*** SYMBOL & COMMENT ***) ;

@ LAD

TITLE

(*** LADDER DIAGRAM ***) ;

@ STEP

TITLE

(*** STEP SEQUENCE DIAGRAM ***) ;

@ IO

TITLE

(*** I/O MODULE DATA ***) ;

@ MSG

TITLE

(*** MESSAGE DATA ***) ;

@ TIT

TITLE

(*** TITLE DATA ***) ;

@ CRS

TITLE

(*** CROSS-REFERENCE ***) ;

@ BIT

TITLE

(*** BIT ADDRESS MAP ***) ;

60 half-size (or 30 full-size) characters>) ;

Notes

1 These point of changes are in the file, I_PRTOUT. ENG.

2 One–byte katakana characters cannot be used.

(8) Setting the cross-reference list output format guidance information

This item can specify characters to be output as guidance information

to be output during cross-reference listing. In the CROSSINF.DAT

file, lines with no semicolon at the beginning are valid as guidance

information.

Name of file to be

edited

Point of change Settings

CROSSINF.DAT GUIDE= Any character string consisting

of up to 19 bytes

(9) Setting the cross-reference list output information

This item can specify step and/or net numbers to be output as

cross-reference information. If both step and net numbers are

specified, which is to be printed first can also be specified. In the

CROSSINF.DAT file, lines with no semicolon at the beginning are

valid as cross-reference information.
