3. OPERATION

B–62884EN/01

228

(3) Reserved symbols

1) ; This special character is reserved for use in ladder data.

D A semicolon is used in the ladder data section to separate ladder

data from a comment. Characters that follow a semicolon are

treated as a comment. When a mnemonic file is converted back

to a source program, a semicolon and a comment that follows

it are not generated.

2) : This special character is reserved for use in ladder and I/O

module data.

D A colon is used in the ladder data section to separate a net

number from ladder data. Data that precedes a colon is treated

as a net number.

D A colon is also used in the I/O module data section to separate

a channel number from I/O module data. Data that precedes a

colon is treated as a channel number.

(4) Control character

The dollar character ”$” is used as control character in the mnemonic

file. Every dollar character in the sentence must be described as ”$$”

in the mnemonic file.

(a) Symbol and comment data

1) Description of address and symbol

Describe the address data and the symbol strings in a same line.

Describe the address data to top of line and the symbol strings

describe after address data with blank character or horizontal

tabulation character as delimitter.

| R0200.0 UNIT–3–POWER

Symbol

Blank character or horizontal tabulation character

Address

2) Description of relay comment and coil comment

Describe the relay comment and coil comment after address

defined in (1).

The first string between two single quotation marks after mark

”$1” is relay comment. And next string between two single

quotation marks is coil comment.

| $1 ’KEEP POWER ON’ ’KEEP UNIT-3 POWER ON’

Coil comment

Blank character or horizontal tabulation character

Relay comment

Mark of comment data

line (only ’$1’)

Blank character or horizontal tabulation character

When relay comment is not used, a part of relay comment must be

described by double single quotation marks.
