Open CNC (Ladder Editing Package) Operators manual Page 18

Operators manual
B–62884EN/01
1. GENERAL
13
(b) For ladder sequence program
Specification Net comment
Available characters ASCII characters
Japanese kana/kanji characters
Line feed
Steps to occupy 2 step/Net comment
Maximum characters/line 64 characters/line
4095 characters/Net comment (Note 1)
Maximum lines 100 lines/Net commennt (Note 1)
Maximum number About 20,000 Net comments (Note 2)
Notes
1. The limitation which is reached first becomes the limitation for the
Net comment.
2. Number of characters in each Net comment effects on maximum
number of Net comments. Free area size of hard disk drive, EMS
and XMS on personal computer may further restrict them.
