Open CNC (Ladder Editing Package) Operators manual Page 27

Operators manual
2. CONFIGURATION AND INSTALLATION OF
PACKAGE
B–62884EN/01
22
The following describes the installation of the Ladder Editing Package
from floppy disk drive A to hard disk drive C.
(1) Insert Vol. 1 into drive A.
(2) Enter “A:¥INSTALL” at the DOS command prompt.
> A : ¥INSTALL
(3) The installer is started, and the title screen appears. Select [Continue].
(4) Enter the hard disk drive to which the software is to be installed
(Note).
Install to :
Enter disk drive name to install the
Ladder Editing Package:
C
Ok Quit
Fig.2.3.2(a)
(5) Specify an OPEN CNC interface type. If the OPEN CNC is already
installed in the personal computer, the interface type is automatically
identified by the installer, and the dialog box shown below appears.
After checking that the interface type detected by the installer is
correct, select [Ok].
Interface Type 1 is detected.
Ladder Editing Package for Type 1 will be installed.
Ok Quit
Fig.2.3.2(b)
If the OPEN CNC is not installed in the personal computer yet, the
dialog box shown below appears. Select the interface type
corresponding to the OPEN CNC to be installed.
2.3.2
Installing the Software
to Invoke from the DOS
Command Prompt
