Open CNC (Ladder Editing Package) Operators manual Page 147

Operators manual
3. OPERATION
B–62884EN/01
142
iii) Examples
Example 1. Combining a sequence program file
[Operation]
1) Place the cursor on the insertion point on the original
screen.
2) Select [File].
3) Enter the name of the file to be combined and press the
Enter
key.
4) From the following menu, select F1 (To).
F1 To
F2 View
F3 Cancel
5) The file is inserted immediately above the net specified
in step 1). (Original screen)
Example 2. Combining a modified sequence program
[Operation]
1) Place the cursor on the insertion point on the original
screen.
2) Select [File].
3) Enter the name of the file to be combining and press the
Enter
key.
4) From the following menu, select F2 (View).
F1 To
F2 View
F3 Cancel
5) Edit the Ladder program on the view screen. To
terminate editing, press the
Esc
key. (Ladder editing
can be performed and terminated in the conventional
way.)
6) From the following menu, select F1 (Save).
F1 To
F2 View
F3 Rename & Save
F4 Edit
F5 Create Latemp file
7) Return to the screen of step 4) and check the name of the
file output in step 6). Then, select F1 (To).
8) The file is inserted immediately above the net specified
in step 1). (Original screen)
Example 3. Combining a specified section of a sequence
program
[Operation]
1) Place the cursor on the insertion point on the original
screen.
2) Select [File].
