B–62884EN/01

4. ERROR MESSAGE LIST

275

Number ContentsMessage

N:E–3172 NET COMMENT CUT ERROR (nn). When nn = –1:

There is insufficient memory.

Reserve an area in extended memory, conventional memory, or on

disk.

When nn = –2:

The net comment file contains invalid data.

Check the net comments using the off–line function.

N:E–3173 NET COMMENT COPY ERROR

(nn).

When nn = –1:

There is insufficient memory.

Reserve an area in extended memory, conventional memory, or on

disk.

When nn = –2:

The net comment file contains invalid data.

Check the net comments using the off–line function.

N:E–3174 NET COMMENT PASTE ERROR

(nn).

When nn = –1:

There is insufficient memory.

Reserve an area in extended memory, conventional memory, or on

disk.

When nn = –2:

The net comment file contains invalid data.

Check the net comments using the off–line function.

N:E–3175 NET COMMENT APPEND ERROR. The net comment file contains erroneous data.

Check the net comments using the off–line function.

N:E–3176 NET COMMENT DELETE ERROR. The net comment file contains erroneous data.

Check the net comments using the off–line function.

N:E–3177 NET COMMENT DATA WRITE

ERROR.

The net comment file contains erroneous data.

Check the net comments using the off–line function.

N:E–3178 NOTHING NET COMMENT DATA. The net comment file contains no net comment within the specified

range.

Check the net comments using the off–line function.

N:E–3183 THIS FUNCTION IS PROTECTED. – On-line editing function and I/O menu functions are protected. Con-

firm keep relay.

– Data table control data screen is protected. Confirm keep relay.

N:E–3184 WRITE PROTECT. (NOT MDI MODE

NOR EMERGENCY STOP.)

PMC parameter is write protected.

Set CNC mode to MDI or emergency stop, or stop the sequence pro-

gram.

N:E–3185 WRITE PROTECT. (CHECK PWE.) PMC parameter is write protected.

Set CNC parameter PWE=1, or stop the sequence program.

N:E–3186 WRITE PROTECT. (CHECK PWE

AND KEY4.)

PMC parameter is write protected.

Set CNC parameter PWE=1, or set KEY4=1, or stop the sequence

program.

N:E–3187 WRITE PROTECT. Signal status is write protected.

Confirm keep relay.
