3. OPERATION

B–62884EN/01

194

Environment settings for diagram output - example 4 (sample setting 2

of the CROSSINF.DAT file)

D Sample setting of the CROSSINF.DAT file

GUIDE=step number

NET-INF=0

STEP-INF=1

FROM=S%s

READ=read

WRITE=write

NL=0

FF=0

;

D Sample cross reference output

[C:¥DATA¥SAMPLE]

*** Cross reference *** PAGE 1

Step number

Address Symbol Comment

MULTIPLE COIL USED

X0.0

Read : S00045 S00049 S00053 S00082 S00088 S00094

X0.1

Read : S00050 S00054 S00059 S00065 S00077

Y0.0

Write: S00045 S00128 S00256

R0.0

Read : S00009 S00012 S00014 S00015 S00022 S00024 S00033 S00045

S00047 S00074 S00079

Write: S00002

Upon the completion of installation, the default printer is set to EPSON

VP1000.

(1) Changing the printer specification to NEC PR201

To enable output to an NEC PR201 printer, change the setting file by

means of the procedure described below. (In the following example,

the floppy disk drive is drive A, installed drive is under the C: \

FLADDER directory, and the file is changed from the DOS prompt.)

[Operation]

1) Copy the AMROFTRP.PR file from the APPENDIX directory of

Volume 1.5 of system floppy disk to the install directory.

Example:C: \ CD FLADDER

Enter

C: \ FLADDER>COPY A: \ APPENDIX \

AMROFTRP.PR C:

Enter

3.5.3.6

Changing the Printer

Specification
