Open CNC (Ladder Editing Package) Operators manual Page 64

Operators manual

Page of 328

/ 328

B–62884EN/01

3. OPERATION

(f) Inserting a net, line, or element

1) Inserting a net

Key :

Ctrl

[Netlns]

Function : Inserts a single blank net after the net at the cursor

position.

2) Inserting a line

Key :

Ctrl

[Lilns]

Function : Inserts a single blank line under the line to which the

cursor is positioned.

3) Inserting an element

Key :

Ctrl

[Elmlns]

Function : Inserts a single blank element at the cursor position.

(g) Cut and paste function

1) Specifying a range

Key :

Ctrl

[Select]

Function : Specifies the range to be cut or copied. The range is

specified by means of the following procedure:

i) Position the cursor to the first net in the desired

range.

ii) Press the

Ctrl

and

keys. (SEL is displayed

at the bottom right corner of the screen.)

iii)Position the cursor to the last net in the desired

range.

Cutting and copying of a specified net range is

explained in 2) or 3) below.

Cancel : Press the

Ctrl

and

keys in range mode.

2) Cutting a net

Key :

Ctrl

[Cut]

Function : Cuts a net. When a net range is specified, the

specified net range is cut. The cut portion is saved in

the buffer for subsequent pasting.

3) Copying a net

Key :

Ctrl

[Copy]

Function : Copies a net into the buffer for subsequent pasting.

When a net range is specified, the specified range is

copied.

4) Pasting a net

Key :

Ctrl

[Paste]

Function : Writes a net that was previously cut or copied and

saved into the buffer.
