Open CNC (Ladder Editing Package) Operators manual Page 65

Operators manual
3. OPERATION
B–62884EN/01
60
(h) Cursor
1) Move cursor Up/Down
Key : ,
Function : Up/Down cursor, When press at the top of the
screen or press
at the bottom of the screen, the
screen scrolls.
2) Move cursor to Left/Right
Key :
,
Function : Move cursor to the left/light. When pressing at
the left end of the screen, the cursor moves to one line
above and right end. When pressing
at the right
end of the screen, the cursor moves one line below and
left end.
At the top.bottom of the screen, the screen scrolls.
3) Move to the top of ladder
Key :
Home
Function : Move cursor to the top of ladder.
4) Move cursor to the bottom of ladder
Key :
End
Function : Move cursor to the bottom of ladder.
5) Previous page
Key :
Page
Up
Function : Go to the previous page.
6) Next page
Key :
Page
Down
Function : Go to the next page.
(i) Others
1) Update
Key :
F7
Function : Update the modification to the ladder diagram on
PMC.
Note
When the [UPDATE] function is used, the ladder program
on the PMC is modified.
Before executing this function, check whether modification
of the ladder program is permitted.
Previous page
Next page
