Open CNC (Ladder Editing Package) Operators manual Page 226

Operators manual
B–62884EN/01
3. OPERATION
221
Program option set–up
[C: ¥DATA¥SAMPLE ]
Compile
Decompile
1 EDIT 2 PRINT 3 COMPIL 4 DECOMP5 I/O 6 SET–UP 7 MNEEDT8 UTILTY 9 ONLINE 10 END
Fig.3.5.7
The user can set the compile function options as described below. These
options, when set, are used as the initial values of the compile options for
the off–line function, or are used for compile processing performed with
the on–line functions.
For details of each option, see Section 3.5.4.
(1) Condense
This option specifies whether condense mode is to be used for
compile processing.
(2) Symbol
This option specifies whether to output symbol or comment data to
an object file.
(3) Net comment
This option specifies whether to output net comment data to an object
file.
(4) Password
This option specifies whether to display the password setting dialog
box at compile time.
[NO] : Does not display the dialog box. (Password
setting is disabled.)
[RW&R] : Displays the password (R/W) setting dialog box
as well as the password (R) setting dialog box.
[RW] : Displays only the password (R/W) setting dialog
box.
[R] : Displays only the password (R) setting dialog
box.
3.5.7.1
Compile
