Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B Connection manual (Hardware) Page 18

Connection manual (Hardware)
1. CONFIGURATION
B–63523EN/03
2
The i series control units are divided into two types: the LCD–mounted
type and stand–alone type.
LCD–mounted type control units have a built–in display. Stand–alone
type control units have a separate display unit. In the following sections,
the LCD–mounted type is also referred to as the LCD–mounted type, and
the stand–alone type is also referred to as the stand–alone type.
The configuration and component names of each type are shown in the
figures given below. This manual explains how to attach the connectors
shown in these figures to devices. The numbers in parentheses () in the
figures are keyed to the item numbers of the descriptions in this manual.
The numbers in brackets [] in the figures are connector numbers.
Series 16i/18i/21i LCD–mounted type control units (A circle in the table
denotes that a unit is available.)
Display
Expansion
slot
Soft key 16i 18i 21i
8.4″ TFT color
None 5+2 f f f
LCD
2 5+2 f f f
3 5+2 f f
4 5+2 f f
10.4″ TFT color
None 10+2 f f f
LCD
2 10+2 f f f
3 10+2 f f
4 10+2 f f
10.4″ TFT color
None None f f f
LCD (with touch
panel)
2 None f f f
3 None f f
4 None f f
7.2″ STN
None 5+2 f f f
monochrome LCD
2 5+2 f f f
3 5+2 f f
4 5+2 f f
9.5″ STN
None 10+2 f f f
monochrome LCD
2 10+2 f f f
3 10+2 f f
4 10+2 f f
1.1
CONTROL UNIT
CONFIGURATION
AND COMPONENT
NAMES
1.1.1
Configurations of
LCD–mounted Type
Control Units
