Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B Connection manual (Hardware) Page 347

Connection manual (Hardware)

Page of 611

/ 611

B–63523EN/03

9. CONNECTION TO FANUC I/O Link

331

The maximum number of β amplifiers with I/O Link that can be

connected to a control unit depends on the maximum number of FANUC

I/O Link points provided by that control unit, as well as their assignments.

For the i Series, the maximum number of FANUC I/O Link DI and DO

points are 1024 and 1024, respectively. One β amplifier with I/O Link

occupies 128 DI/DO points in the FANUC I/O Link. If no units other than

the β amplifiers with I/O Link are connected to the control unit, up to eight

β amplifiers can be connected.

If the β amplifier with I/O Link is used as an I/O Link slave, I/O addresses

are assigned in the PMC in the CNC. Because data output from the slave

is made in 16–byte units, the number of input/output points must be set

to 128.

The module names are OC02I (input) and OC02O (output).

The BASE is always 0, and the SLOT is 1.

9.11.3

Maximum Number of

Units that can be

Connected

9.11.4

Address Assignment

by Ladder
