1. Fanuc
  2. Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B

Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B Connection manual (Hardware) Page 439

Connection manual (Hardware)
B–63523EN/03
12. HIGH–SPEED SERIAL BUS (HSSB)
423
CAUTION
1 The machine tool builder or end user is required to procure
and maintain the personal computer.
2 FANUC is not liable for any problems resulting from the
operation of users’ personal computers, regardless of
whether the operations are normal or abnormal.
D This interface board for the personal computer is based on the ISA
specifications and it can be used into IBM–PC/AT or full compatible
computer. (CPU of the computer must be more than 486.)
D The HSSB interface board uses 16 bytes of I/O space defined with
rotary switch as mentioned in ”MAINTENANCE – Setting of
Switched”. The other ISA extension boards that use the same resource
with HSSB board can not be used.
D Driver installation is required for using HSSB interface board. The
driver for the HSSB interface board is included in ”Open CNC Driver
Libraries Disk (order specification is A02B–0207–K730).
D Please examine the connection test including the communication
between the personal computer and CNC controller sufficiently.
D Following shows the required power of the interface board for ISA
type.
1ch version DC +5V, 1A
2ch version DC +5V, 1.5A
D This interface board for the personal computer is based on the PCI
specifications and it can be used into a computer with PCI slot (5V,
ISA slot type).
D Driver installation is required for using HSSB interface board. The driver
for the HSSB interface board is included in ”Open CNC Driver Libraries
Disk (order specification is A02B–0207–K730). The revision of the
driver must be Edition 1.6 or later for the board of PCI type.
D Please examine the connection test including the communication
between the personal computer and CNC controller sufficiently.
D Following shows the required power of the interface board for PCI type.
1ch version DC +5V, 0.8A
2ch version DC +5V, 1.0A
12.4
PERSONAL
COMPUTER
SPECIFICATION
12.4.1
Specification of
Personal Computer in
Case that the Interface
Board of ISA Type are
Used
12.4.2
Specification of
Personal Computer in
Case that the Interface
Board of PCI Type are
Used
