B–63523EN/03

14. CONNECTION FOR Series 160is/180is/210is

437

The control units and peripheral units offered by FANUC are designed on

the assumption that they will be enclosed in a tightly closed cabinet. The

cabinet can be:

D One that is created by the machine tool builder to house a control unit

or peripheral unit,

D Operator’s pendant box created by the machine tool builder to house

a control unit or operator’s panel, or

D The like

The following table lists the environmental conditions for control units

housed in a cabinet listed above.

Condition Series 160is/180is/210is–MODEL B

Ambient temperature

Operating 0°C to 58°C

Storage, Transport –20°C to 60°C

Humidity

Normal 10% to 75%RH, no condensation

Short period (less than 1 month) 10% to 90%RH, no condensation

Vibration

Operating 0.5G or less

Non–operating 1.0G or less

Meters above sea level

Operating Up to 1000m

Non–operating Up to 12000m

Environment Normal machine shop environment

(The environment must be considered if the cabinets are in a location where the density of

dust, coolant, and/or organic solvent is relatively high.)

Using the 160is/180is/210is requires a 24 VDC "10% power input that

satisfies the requirements listed below. The tolerance "10% includes

instantaneous changes and ripples.

Number of

option slot

Power supply

capacity (A)

Heat output

(W)

None 3.4A 45W

LCD–mounted

2 3.5A 48W

LCD–mounted

type

3 3.7A 53W

4 3.8A 54W

CNC display unit

for Windows

— 2.7A 29W

*1:When the power is turned on, 1.5 A is consumed for one minute or so

to charge the backup unit. The power requirements listed above

include this current.

*2:The current used in the LCD and MDI unit is included. No current for

each option board is included. See Section 3.2, ”Power Supply

Capacity,” for information about the power requirements of option

boards.

*3:If power is supplied to a FANUC device, such as Handy File, from the

RS–232–C port, 1 A is needed additionally.

14.2.3

Environmental

Conditions for Control

Units

14.2.4

Power Supply Capacity
