1. Fanuc
  2. Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B

Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B Connection manual (Hardware) Page 220

Connection manual (Hardware)
9. CONNECTION TO FANUC I/O Link
B–63523EN/03
204
:SIN
1
3
SIN
2
SOUT
4
6
:SOUT
5
8
7
9
(+5V)
10
0V
11
13
0V
12
0V
14
16
0V
15
18
17
(+5V)
(+5V)
19
20
JD1A
(PCR–E20MDK–SL–A)
JD1B
(PCR–E20LMD)
JD1B
JD1A
(PCR–E20LMD)
Next slave
unit
:SIN
1
3
SIN
2
SOUT
4
6
:SOUT
5
8
7
9
(+5V)
10
0V
11
13
0V
12
0V
14
16
0V
15
18
17
(+5V)
(+5V)
19
20
Control unit or preceding slave unit I/O unit MODEL A
+5 V terminals are for an optical I/O Link adapter. They are not necessary
when connecting with a metal cable.
A line for the +5V terminal is not required when the Optical I/O Link
Adapter is not used.
Shield
SOUT
:SOUT
SIN
:SIN
0V
0V
0V
0V
SIN
:SIN
SOUT
:SOUT
0V
0V
0V
0V
1
2
3
4
11
12
13
14
3
4
1
2
11
12
13
14
Ground Plate
Cable wirinr
Recommended wire material
A66L–0001–0284#10P(#28AWG 10pair)
Recommended cable connectors
PCR–E20FA (Honda Tsushin Kogyo Co., Ltd.)
FI30–20S (Hirose Electric Co., Ltd.)
FCN–247J020–G/E (Fujitsu Ltd.)
52622–2011 (Molex Japan Co., Ltd.)
The recommended cable–end connector F130–20S (Hirose Electric Co.,
Ltd.) can be used only as connector JD1A for the i Series CNC with a
LCD–mounted type panel.
9.2.1
Connection of FANUC
I/O Link by Electric
Cable
