Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B Connection manual (Hardware) Page 587

Connection manual (Hardware)

Page of 611

/ 611

B–63523EN/03

F. MEMORY CARD INTERFACE

571

3. Flash ATA cards whose normal operation has been confirmed

The following table shows that the ATA Flash cards which are

confirmed to be worked on the Series 16i/18i/21i–MODEL B

(note

by FANUC. (for February, 2001)

The marks on the table mean bellow.

Available: The card confirmed to be worked by FANUC

NG: FANUC does not recommend to use it because it might

need much time to write data to the card.

—: No planning to test

FANUC does not guarantee that any other cards except for the list

work well.

NOTE

Following series are exact devices that are confirmed to be

workd.

[For automatic operation from PCMCIA port]

They are used on the CNC side of the LCD–mounted/

Stand–alone Type Series 16i/18i/21i–MODEL B and

Stand–alone Type Series 160i/180i/210i/160is/180is/210is–

MODEL B.

The PSMCIA interface on the CNC display unit for with PC

functions or CNC display unit for is series CNC on the

LCD–mounted Type Series 160is/180is/ 210is–MODEL B is

not included.

[For Data server]

All Series 16i/18i/21i–MODEL B, Series 160i/180i/210i–

MODEL B and Series 160is/180is/210is–MODEL B are

included.
