1. Fanuc
  2. Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B

Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B Connection manual (Hardware) Page 468

Connection manual (Hardware)
14. CONNECTION FOR Series 160is/180is/210is
B–63523EN/03
452
Use this port to connect with the USB keyboard or printer.
LCD–mounted Type CNC and
CNC display unit for Windows
JD48
PCR–E20MD
1RD11SD
2 0V 12 USB_0V
3 Reserve 13 Reserve
4 0V 14 Reserve
5CS15RS
6 USB_+ 16 Reserve
7 Reserve 17 Reserve
8 USB_– 18 Reserve
9 Reserve 19 Reserve
10 Reserve 20 USB_5V
Relay connector
USB
15V
2D–
3D+
40V
(i) Connection (for conversion to the USB connector (type A receptacle))
Recommended connector for cable and housing (JD48 side)
Connector Housing Manufacture
PCR–E20FA PCR–V20LA/ Honda Tsushin
PCS–E20LA Kogyo
FI30–20S FI–20–CV2/ Hirose Electric
FI–20–CV7
FCN–247J020–G/E FCN–240C020–Y/S Fujitsu
52622–2011 52624–2015 Molex Japan
JD48
USB connector
USB_+
USB_–
USB_0V
USB_5V
06
08
12
20
D+
D–
0V
5V
03
02
04
01
Shield
Recommended wire specification:
Use dedicated wire.
NOTE
1 Because not some little incompatibility occurs between
commercial USB devices and USB hosts, FANUC does not
guarantee that all commercial USB devices can operate on
FANUC products. The machine tool builder should check
their operability carefully. Also note that no commercial
USB device is usually designed for dust or drip resistance.
2 Generally, USB devices can be connected to a PC with its
power kept on (hot plugging). However, this connector
(JD48) does not support hot plugging. Using a USB
connector (type A receptacle) as a junction connector
supports hot plugging outside the USB junction connector.
3 The USB power supply (5 V) can supply up to 500 mA.
4 Ground the USB connector to a grounding plate.
14.3.4.2
USB port
