9. CONNECTION TO FANUC I/O Link
B–63523EN/03
384
Directly processed address by CNC (in case of FS16I, 18i, 21i)
7 6 5 4 3 2 1 0
SKIP#1 ESKIP –MIT2#1 +MIT2#1 –MIT1#1 +MIT1#1 ZAE#1 XAE#1
SKIP6#1 SKIP5#1 SKIP4#1 SKIP3#1 SKIP2#1 SKIP8#1 SKIP7#1
X0004
SKIP#1 ESKIP SKIP5#1 SKIP4#1 SKIP3#1 ZAE#1 YAE#1 XAE#1
SKIP6#1 SKIP2#1 SKIP8#1 SKIP7#1
X0005
X0006
X0007 *DEC7#2 *DEC6#2 *DEC5#2 *DEC4#2 *DEC3#2 *DEC2#2 *DEC1#2
X0008 *ESP
X0009 *DEC7#1 *DEC6#1 *DEC5#1 *DEC4#1 *DEC3#1 *DEC2#1 *DEC1#1
X0010
X0011
X0012
SKIP#2 SKIP6#2 –MIT2#2 +MIT2#2 –MIT1#2 +MIT1#2 ZAE#2 XAE#2
SKIP5#2 SKIP4#2 SKIP3#2 SKIP2#2 SKIP8#2 SKIP7#2
X0013
SKIP#2 SKIP6#2 SKIP5#2 SKIP4#2 SKIP3#2 ZAE#2 YAE#2 XAE#2
SKIP2#2 SKIP8#2 SKIP7#2
#1 means the signales in 1st path. #2 means the signals in 2nd path. And up column means the T series signals and down
column means the M series signals.
Ex. In case of 16 byte mapping start from X006 for DI area.
X0006
X0007
General–purpose
X0008
X0009
X0010
X0011
X0012
X0013 Keyboard of
Main panel
(Keyswitches)
X0014
X0015
X0016
X0017
X0018 (1st MPG)
X0019 (2nd MPG) MPG
X0020 (3rd MPG)
X0021 Reserve
*DECn#2 Fixed signals
*ESP Fixed signal
In case of mapping start from X0006, *DECn#1 and
*DECn#2 singals which are address fixed signals can
be used any time. And *ESP signal can be placed at
+24V common fixed address.
But SKIP signals can not be used.
Don’t map the *ESP signal matrix DI area.
*DECn#1 Fixed signal
