Series 16i/18i/160i/180i - PB Connection manual (Function) Page 128

Connection manual (Function)
6. C–AXIS CONTROL
B–63683EN/01
118
#7
SYNC8G140
#6
SYNC7
#5
SYNC6
#4
SYNC5
#3
SYNC4
#2 #1 #0
#7
F233
#6 #5 #4 #3 #2 #1
SC2
#0
SC1
#7
16360
#6 #5 #4
ACS
#3 #2 #1 #0
SYN
[Data type] Bit
SYN C–axis synchronous control is:
0 : Disabled.
1 : Enabled.
ACS Under C–axis synchronous control, synchronization is:
0 : Disabled.
1 : Enabled.
16364 Upper limit of error under C–axis synchronous control
[Data type] Word
[Unit of data] Units of detection
[Valid data range] 0 to 32767
When the absolute value of the position error between the C
1
–axis and
C
2
–axis exceeds the value set in this parameter under C–axis synchronous
control, alarm 4603 occurs.
16365 Upper limit of error under C–axis synchronous control (during continuous pressing)
[Data type] Word
[Unit of data] Units of detection
[Valid data range] 0 to 32767
When the absolute value of the position error between the C
1
–axis and
C
2
–axis exceeds the value set in this parameter while continuous pressing
signal NBL is set to 1, alarm 4603 occurs.
16368 Maximum compensation in C–axis synchronization
[Data type] Word
[Unit of data] Units of detection
[Valid data range] 0 to 65535
This parameter specifies the maximum compensation in C–axis
synchronization under C–axis synchronous control. If an actual
compensation value exceeds this value, an excessive error alarm occurs in
the stop state or during travel.
