Series 16i/18i/160i/180i - PB Connection manual (Function) Page 16

Connection manual (Function)
1. LIST OF FUNCTIONS
B–63683EN/01
6
No.
Whether
supported
Item
7 Feedrate control/acceleration and
deceleration control
7.1 Feedrate control
Rapid traverse rate ∆: See chapter 2
Cutting feedrate clamp f
Feed per minute f
Feed per revolution/manual feed per
revolution
×
F1–digit feed ×
Feedrate inverse time specification ×
Rapid traverse override ∆: See chapter 2
Feedrate override f
Second feedrate override f
Override cancel f
Automatic corner override f
External deceleration f
Feed stop function f
Feedrate clamping by arc radius (M series) f
Automatic corner deceleration f
Advanced preview control ∆: See chapter 2
High–precision contour control by RISC ×
Positioning by optimal acceleration ×
AI contour control/AI nano contour control ×
AI advanced control ×
AI high–precision contour control/AI nano
high–precision contour control
×
RISC processor operation ×
High–speed linear interpolation ×
Previous page
Next page
