Compound Machining Additional Manual Page 101

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 101/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Item Specifications
Turning
mode
Milling
mode
Axis recomposition -
Simple synchronous control -
Twin table control -
Angular axis control -
Arbitrary angular axis control
I
B-axis control -
Tandem control -
Torque control PMC axis control is required.
S
Control axis detach -
Chopping -
Function for hobbing machine -
I
Simple electric gear box -
Least input increment 0.001mm, 0.001deg, 0.0001inch Ο
Increment system 1/10 0.0001mm, 0.0001deg, 0.00001inch
I
Flexible feed gear Optional DMR Ο
Learning control -
Preview repetitive control -
Dual position feedback
I
Fine Acc. & Dec. control Ο
HRV control Ο
Inch/metric conversion
I
Interlock All axes / each axes / each direction /
block start / cutting block start
Ο
Machine lock All axes / each axes Ο
Emergency stop Ο
Overtravel Ο
Stored stroke check 1 Ο
Stroke limit external setting -
I
