Compound Machining Additional Manual Page 98

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 98/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
5 Additional signals
The following signals have been added for the function.
5.1 DI signal
Address 7 6 5 4 3 2 1 0
G193 PTM DTM
DTM The following screen is displayed by this signal.
0: The screen showing turning data is displayed.
1: The screen showing milling data is displayed.
PTM The change between turning mode and milling mode depends on this signal.
(This signal is available when parameter No.13002#1(EPM) is set to 1)
0: Turning mode
1: Milling mode
5.2 DO signal
Address 7 6 5 4 3 2 1 0
F193 PRS
PRS Current mode is:
1: Milling one.
0: Turning one.
5.3 R area
Address 7 6 5 4 3 2 1 0
R???? TRV B90 B00 B-90
B90, B00, B-90 The angle of B-axis inputted from PMC
TRV The direction of the turning tool is outside.
Note
• The address of this signal is specified with the parameter 13040.
