Compound Machining Additional Manual Page 22

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 22/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
2.4.3 Assigning servo axis number
Correspondence between each axis number and servo axis number is not
always the same for both command modes.
Therefore, each axis-type parameter for milling mode must be specified
based on the corresponding axis number for turning mode.
Example)
Turning mode Milling mode Parameter No.13030
X X 1
Z Y 4
C Z 2
Y C 3
2.4.4 Increment unit
Increment unit must be the same for both command modes.
For example, it is impossible to specify IS-B for turning mode and IS-C for
milling.
2.5 Spindle control
2.5.1 Connection
Connection of spindle(serial) would be to motherboard.
It is available to use 4 spindles in FS16i, and 3 spindles in FS18.
1
st
to 4
th
spindle that is connected at motherboard are used in both command
mode.
