Compound Machining Additional Manual Page 47

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 47/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Address 7 6 5 4 3 2 1 0
F105
F106 MVD8 MVD7 MVD6 MVD5 MVD4 MVD3 MVD2 MVD1
F107
F108 MMI8 MMI7 MMI6 MMI5 MMI4 MMI3 MMI2 MMI1
F109
F110
MDTCH8 MDTCH7 MDTCH6 MDTCH5 MDTCH4 MDTCH3 MDTCH2 MDTCH1
F111
F112
EADEN8 EADEN7 EADEN6 EADEN5 EADEN4 EADEN3 EADEN2 EADEN1
F113
F114 TRQL8 TRQL7 TRQL6 TRQL5 TRQL4 TRQL3 TRQL2 TRQL1
F115
F116 FRP8 FRP7 FRP6 FRP5 FRP4 FRP3 FRP2 FRP1
F117
F118
F119
F120 ZRF8 ZRF7 ZRF6 ZRF5 ZRF4 ZRF3 ZRF2 ZRF1
F121
F122 HDO7 HDO6 HDO5 HDO4 HDO3 HDO2 HDO1 HDO0
F123
F124
