Compound Machining Additional Manual Page 85

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 85/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
H99; Selects the H code of tool life management data for the tool
currently being used.
H00; Cancels tool length offset.
D99; Selects the D code of tool life management data for the tool
currently being used.
D00; Cancels cutter compensation.
Example) Parameter No. 6810 = 100 (Tool life management cancel number)
Oxxxx;
T0101; A tool whose life has not expired is selected from group 1.
(Suppose that tool number 010 is selected.)
M06; Tool life counting is performed for the tool in group 1.
(The life of tool number 010 is counted.)
T0102; A tool whose life has not expired is selected from group 2.
(Suppose that tool number 100 is selected.)
M06T0101; Tool life counting is performed for the tool in group 2.
(The life of tool number 100 is counted.)
The number of the tool currently used (in group 1) is output
with a T code signal. (Tool number 010 is output.)
Note
H99 or D99 must be specified after the M06 command. When a code
other than H99 or D99 is specified after the M06 command, the H code
and D code of tool life management data are not selected.
