Compound Machining Additional Manual Page 34

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 34/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Address 7 6 5 4 3 2 1 0
G125
G126 SVF8 SVF7 SVF6 SVF5 SVF4 SVF3 SVF2 SVF1
G127
G128 MIX8 MIX7 MIX6 MIX5 MIX4 MIX3 MIX2 MIX1
G129
G130 *IT8 *IT7 *IT6 *IT5 *IT4 *IT3 *IT2 *IT1
G131
G132 +MIT4 +MIT3 +MIT2 +MIT1
G133
G134 -MIT4 -MIT3 -MIT2 -MIT1
G135
G136 EAX8 EAX7 EAX6 EAX5 EAX4 EAX3 EAX2 EAX1
G137
G138
G139
G140
G141
G142 EBUFA ECLRA ESTPA ESOFA ESBKA EMBUFA EFINA
G143 EMSBKA EC6A EC5A EC4A EC3A EC2A EC1A EC0A
G144 EIF7A EIF6A EIF5A EIF4A EIF3A EIF2A EIF1A EIF0A
G145 EIF15A EIF14A EIF13A EIF12A EIF11A EIF10A EIF9A EIF8A
