Compound Machining Additional Manual Page 118

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 118/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Data input/output
Item Specifications
Turning
mode
Milling
mode
Reader/puncher interface Reader/puncher (Ch.1) interface
I
Reader/puncher (Ch.2) interface
I
Input/output simultaneous operation -
Remote buffer
I
High-speed remote buffer A -
High-speed remote buffer B -
Data server
I
External I/O device control
I
DNC1 control Uploading/downloading a part program,
Reading/writing CNC data, Transfer of
PMC data, Memory operation control, etc.
-
DNC2 control -
Modem card control Ο
External tool offset
I
External message
I
External machine zero point shift
I
External data input Including above 3 items
I
External key input Ο
External program input Ο
External workpiece number search 9999 Ο
External program number search 1~9999
S
Memory card input/output Ο
Screen hard copy Ο
Power mate CNC manager
I
